Overview Cisco Meraki MS220-48-HW

Highlights

Configurations

• • • All models: 48 port gigabit Ethernet
    • All models: 4 × SFP for 1G uplink, non-shared
    • MS220-48LP includes 370 W PoE / PoE+
    • MS220-48FP includes 740 W PoE / PoE+

Hardware platform

• • • Voice and Video QoS
    • Supports Cisco redundant power system (RPS2300)
    • Non-blocking switch fabric
    • Ultra-reliable, includes lifetime warranty

Power over Ethernet (for PoE models)

• • • 802.3af (PoE) 15.4 W per port
    • 802.3at (PoE+) 30 W per port
    • MS220-48LP maximum PoE output: 370 W
    • MS220-48FP maximum PoE output: 740 W
    • PoE available simultaneously on all ports
    • Intelligent PoE power allocation based on device advertisement (LLDP)

Cloud management

• • • Visibility and control over thousands of ports
    • Built-in multi site management
    • Zero touch provisioning

Monitoring and diagnostics

• • • Cable failure testing
    • Gateway connectivity testing
    • Real time troubleshooting tools
    • Email and text message alerts

Specifications

Interfaces

• 48 × 10/100/1000BASE-T Ethernet (RJ45) with auto-MDIX crossover
• 48V DC 802.3af/802.3at Power-over-Ethernet (PoE/PoE+) on the MS220-48P models, available on all ports (maximum of 30W per port for PoE+)
• 4 × SFP Gigabit Ethernet interfaces for uplink
• Auto negotiation and crossover detection

Management

• Managed via the cloud using the Meraki dashboard
• Integrated with Meraki wireless, routing, and firewall management
• No-touch remote deployment (no staging needed)
• Detailed historical per-port and per-client usage statistics
• DHCP and hostname fingerprinting
• SNMP v2c
• Seamless over-the-web firmware upgrades

Remote diagnostics

• Email and text alerts
• Live remote packet capture
• Aggregated event logs with instant search

Scalable stacking

• Virtually stack thousands of switch ports in a single logical stack for unified management, monitoring, and configuration

Ethernet switching capabilities

• 802.1p Quality of Service prioritization
• 802.1Q VLAN tagging with 4,095 addressable tags
• 802.1D Spanning Tree Protocol (STP) and 802.1w Rapid Spanning Tree
• Broadcast storm control
• 802.1ab Link Layer Discovery Protocol (LLDP) and Cisco Discovery Protocol (CDP)
• 802.3ad Link aggregation with up to 8 ports per aggregate
• Port mirroring
• IGMP snooping for multicast
• MAC forwarding table entries: 16K

Security

• Integrated two-factor authentication
• Role-based administration
• Corporate wide password policy enforcement
• IEEE 802.1X port-based security
• MAC-based RADIUS authentication
• Port security: Sticky MAC, MAC whitelist
• MAC whitelisting
• STP Enhancements: BPDU guard, Root guard
• Hybrid authentication
• IPv4 ACLs

Performance

• Non-blocking fabric
• 104 Gbps non-blocking switching capacity
• 2.5 microsecond latency

Power over Ethernet (PoE models):

• 802.3af (PoE) 15.4 W per port and 802.3at (PoE+) 30 W per port
• MS220-48LP maximum PoE output: 370 W
• MS220-48FP maximum PoE output: 740 W
• PoE available on all ports simultaneously

Layer 3 capabilities

• DHCP Relay only

Power

• Power input: 100-240 VAC, 47-63 Hz
• MS220-48 power consumption: 28-51 W max
• MS220-48LP power consumption: 45-505 W max
• MS220-48FP power consumption: 49-903 W max

Mounting

• 1U Rack-mountable with included rack mount hardware
• 2-post front mounting options available

Environment

• Operating temperature: 32°F to 104°F (0°C to 40°C)
• Humidity: 5 to 95% non-condensing

Regulatory

• CSA-US (US, Canada)
• FCC (USA)
• IC (Canada)
• CE (Europe)
• RCM (Australia/New Zealand)
• RoHS

Warranty

• Lifetime hardware warranty with advanced replacement included

MTBF (at 25°C)

• MS220-48: 329,440 hours
• MS220-48LP: 329,440 hours
• MS220-48FP: 329,440 hours

Physical dimensions (H×W×D)

• MS220-48: 1.74″ x 19.1″ x 14.17″ (4.44cm x 48.5cm x 35.99cm)
• MS220-48LP: 1.74″ x 19.1″ x 14.17″ (4.44cm x 48.5cm x 35.99cm)
• MS220-48FP: 1.74″ x 19.1″ x 14.17″ (4.44cm x 48.5cm x 35.99cm)

Physical Weight

• MS220-48: 11.38 lb (5.16 kg)
• MS220-48LP: 12.62 lb (5.72 kg)
• MS220-48FP: 13.13 lb (5.95 kg)
